Architecture of an Activity-REST service

The following figure presents the main components of an Activity-REST RIM-compliant adapter service. The RIM-compliant adapter includes the Activity-REST framework as one of the main dependencies, and executes on a Runtime System (OS and an application container) that supports the execution of the Functional Entity (an underlying command line analysis tool).

Creating a new RIM-compliant adapter service

Project file organization

After the creation of the adapter project using the provided Maven archetype as presented in the usage section, a folder containing the project base source code is created. This folder presents the following overall organization:

<project_root>
  | - src/${MY_GROUP_ID}
  |     | - ApplicationConfig.java // Configuration Code Component
  |     | - activity.aadl          // the activity description
  |     | - activityrest.properties // Configuration Code Component
  | 	| - <other Java classes for Activity-REST Extension
  |     |   component may be created here, i.e., classes for extenal
  |     |   contraint validators>
  |
  | - tests/
  |     | - <Unit tests can be created here>
  |
  | - WebContent/
  |     | - <JAX-RS folder for static files (currently empty)>
  |
  | - target/
  |     | - <Will contain the compiled project WAR>
  |
  | - pom.xml // Maven dependencies and build configuration for project

Configuration Code component

The configuration code component initializes the Activity-REST framework. The main unit of this component is the class ApplicationConfig.java. ApplicationConig.java defines a JAX-RS service application, creates an ActivityRestConfiginstance on its constructor and then uses it to initialize the Activity-REST framework.

The minimal ApplicationConfigclass is presented in the next code block. This class needs to be changed only if the framework is extended by new constraint validators and/or endpoints.

ApplicationConfig.java

package br.usp.ffclrp.dcm.lssb.geas.deseq2analsyis;

import java.io.File;
import java.io.IOException;
import java.util.HashMap;
import java.util.Map;
import java.util.Properties;
import java.util.Set;
import javax.ws.rs.ApplicationPath;
import br.usp.ffclrp.dcm.lssb.activityrest.dao.FileSystemActivityRepository;
import br.usp.ffclrp.dcm.lssb.activityrest.rest.ActivityRestConfig;
import br.usp.ffclrp.dcm.lssb.activityrest.rest.BasicApplicationJAXRSConfig;
import br.usp.ffclrp.dcm.lssb.activityrest.util.ModelsService;
import br.usp.ffclrp.dcm.lssb.restaurant.analysisactivitydescription.Activity;

@ApplicationPath("/")
public class ApplicationConfig extends BasicApplicationJAXRSConfig {

	final String ACTIVITYREST_PROPERTIES = "activityrest.properties";
	static final String ACTIVITY_DESCRIPTION = "activity.aadl";

	ActivityRestConfig config;

	public ApplicationConfig() {
		super();

		this.config = new ActivityRestConfig();
		try {
			Activity activityModel = ModelsService.retrieveAADLModel(
					this.getClass().getResourceAsStream(
							ACTIVITY_DESCRIPTION));

			this.config.setActivityModel(activityModel);
			Properties deploymentProperties = new Properties();
			deploymentProperties.load(
					this.getClass().getResourceAsStream(ACTIVITYREST_PROPERTIES));

			File nonExecutedActivityStorage = new File(deploymentProperties.getProperty("activityrest.repositories.nonExecuted"));
			this.config.setNewAnalysisRepository(
					new FileSystemActivityRepository(nonExecutedActivityStorage, activityModel));

			File runningActivityStorage = new File(deploymentProperties.getProperty("activityrest.repositories.running"));
			this.config.setRunningAnalysisRepository(
					new FileSystemActivityRepository(runningActivityStorage, activityModel));

			File failedActivityStorage = new File(deploymentProperties.getProperty("activityrest.repositories.failed"));
			this.config.setFailedAnalysisRepository(
					new FileSystemActivityRepository(failedActivityStorage, activityModel));

			File succeededActivityStorage = new File(deploymentProperties.getProperty("activityrest.repositories.succeeded"));
			this.config.setSuccededAnalysisRepository(
					new FileSystemActivityRepository(succeededActivityStorage, activityModel));

		} catch (IOException e) {
			// TODO Auto-generated catch block
			e.printStackTrace();
		}
	}

	@Override
	public Set<Class<?>> getClasses() {
		Set<Class<?>> resources = super.getClasses();

		// add here all classes with JAX-RS annotations

		return resources;
	}

	@Override
	public Map<String, Object> getProperties() {
		Map<String, Object> map = new HashMap<String, Object>();
		map.put("activityrest.config", this.config);
		return map;
	}

}

The Configuration Code component passes the ActivityRestConfig object to the Activity-REST framework through the map created in the getProperties() method (map key activityrest.config.

The previous code refers to two other files of the project. The activityrest.properties file contains information that may change in different deployiments of the service. Here you may change the folders where the activity repositories (part of the Persistence Manager component) will persist the analysis activity instances created by the user. DO NOT use the same folder for two different repositories. A example configuration is presented in the next code block:

activityrest.properties:

activityrest.repositories.nonExecuted = /tmp/deseq2-analysis/new-analyses
activityrest.repositories.succeeded = /tmp/deseq2-analysis/succeeded-analyses
activityrest.repositories.failed = /tmp/deseq2-analysis/failed-analyses
activityrest.repositories.running = /tmp/deseq2-analysis/running-analyses

Activity-REST Extensions component

New constraint validators and endpoints may be added to a Activity-REST service through the creation of dedicated Java classes. These classes must also be referenced by the Configuration Code component in order to be accessible by the framework. Note that this feature is still in an unstable state and may have slight changes in future.

In order to create a new external constraint validator, the developer must implement one of the constraint validation interfaces: ParameterValidator and InputDatasetValidator. Both interfaces provide a single method validate() that must be implemented in order to validate new parameter values or the submitted file for a input dataset and return an instance of the class ValidationResult. These methods will be called by the Activity-REST framework when a service user submits new parameter values and new files for the input datasets.

Note: Constraint validators MUST NOT change the values received.

ParameterValidator::validate() receives the name of the parameter the constraint is applied to (the parameter recently changed), a ParameterMap instance containing the new values for all the parameters of the analysis activity instance and a reference for the AnalysisActivity instance.

package br.usp.ffclrp.dcm.lssb.activityrest.domain.validation;

import br.usp.ffclrp.dcm.lssb.activityrest.domain.AnalysisActivity;

public interface ParameterValidator {

	 public ValidationResult validate(
			 String parameterName,
			 ParameterMap newValues,
			 AnalysisActivity activityInstance);

}

Usually a parameter validator will use the received parameter name to fined the parameter new value in the received map in order to validate this value. The AnalysisActvity instance can also be read in order to implement validations that depends on the files of the input datasets.

InputDatasetValidator::validate() receives the changed (input) dataset and the AnalysisActivity instance. Usually, an input dataset validator will check the contents of the files in the input dataset and validate them. However, the instance of AnalysisActivity can be also read in order to implement constraint validations that also depends of the current value of execution parameter and other input datasets.

package br.usp.ffclrp.dcm.lssb.activityrest.domain.validation;

import java.io.File;
import br.usp.ffclrp.dcm.lssb.activityrest.domain.AnalysisActivity;
import br.usp.ffclrp.dcm.lssb.restaurant.analysisactivitydescription.Dataset;

public interface InputDatasetValidator {

	public ValidationResult validate(
			Dataset dataset,
			AnalysisActivity activityInstance);

}

The new validation classes must be instantiated and the derived instances must be referenced by the Configuration Code component using the external constraint identifier presented in the activity’s AADL description.

For example, let’s create an email validator for an execution parameter and a maximum file size validator for an input dataset. First, we define the constraint identifiers in the activity.aadl file:

activity my-analysis {
	on {
		dataset samples : 'text/tsv' [1,-1] {
			constraints ['maxFileSize'];
		};
		// other datasets...
	}
	with {
		parameter email : STRING [1,1]{
			contraints ['isEmail'];
		};
		// other parameters
	}
	produces {
		// output dataset declarations
	}
	using executable // tool description  ...
}

Then, we implement ParameterValidator and InputDatasetValidator with the validation code. For the email validation, we will wrap an existing Apache Commons validator (This is not a default Java package and the Apache Commons Validator bundle must be included as dependency in the pom.xml file).

EmailValidator.java:

import org.apache.commons.validator.routines.EmailValidator;

public class EmailValidator implements ParameterValidator {

	 public ValidationResult validate(
			 String parameterName,
			 ParameterMap newValues,
			 AnalysisActivity activityInstance){

		// get values
		List<Object> values =
			(List<Object>) newValues.get(parameterName);

		// validate all the elements of the list
		for(Object value : values){
			boolean valid =
				EmailValidator.getInstance()
				 .isValid(value.toString());
			if(!valid) {
				return new ValidationResult(false,
					"Bad email");
			}
		}

		// return valid if arrived here
		return new ValidationResult(true,null);

	}
}

For the file size validation, we can use the File::length()method of the Java API:

MaximumFileSizeValidator.java:

public class MaximumFileSizeValidator implements InputDatasetValidator {

	final long MAX_SIZE = 1_000_000; // 1MB

	public ValidationResult validate(
			Dataset dataset,
			AnalysisActivity activityInstance){
		for(File f : dataset.getFiles()) {
			// validate each file
			if(f.length() > MAX_SIZE) {
				return new ValidationResult(false,
					"File too big!"
					+ "Maximum: "
					+ MAX_SIZE +
					" bytes!");
			}
		}

		// return valid if arrived here
		return new ValidationResult(true,null);

	}

}

Finally, we instantiate both classes and includes then in the ActivityRestConfig object created in the Configuration Code component.

@ApplicationPath("/")
public class ApplicationConfig extends BasicApplicationJAXRSConfig {

	final String ACTIVITYREST_PROPERTIES = "activityrest.properties";
	static final String ACTIVITY_DESCRIPTION = "activity.aadl";

	ActivityRestConfig config;

	public ApplicationConfig() {
		super();

		this.config = new ActivityRestConfig();
		try {
			// ...
			Map<String,ParameterValidator> parameterConstraints
				= new Map<>();

			parameterConstraint.put("isEmail", new EmailValidator());
			// other constraints ....
			this.config.setParameterConstraints(parameterConstraints);


			Map<String,InputDatasetValidator> datasetConstraints
				= new Map<>();
			datasetConstraints.put("maxFileSize", new FileSizeValidator());
			// other constraints ....
			this.config.setInputDatasetConstraints(datasetConstraints);
			// ...

		} catch (IOException e) {
			// TODO Auto-generated catch block
			e.printStackTrace();
		}
	}

	// ...
}
